GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference.
PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion.
AUTO-SENSING PORTS
Automatically optimize speed for each connected device.
POWER-SAVING FEATURES
The auto power-down feature disables unused ports, smart power is ideal for short cable runs, and the port status switch controls LED lights.
Technical specifications
- Network Standards:
o IEEE 802.3
o IEEE 802.3u
o IEEE 802.3x
o IEEE 802.3ab
o IEEE 802.3az
- Ports:
16 Gigabit Ethernet (10/100/1000) Ports
- LEDs:
Link, speed, and activity indicators
- Performance:
o Full line rate and forwarding rate of 64B frame at:
o 1.488Mpps for 1000M port
o 0.1488Mpps for 100M port
o 0.01488Mpps for 10M port
- MAC Address Table Size:
8K
- Bandwidth:
32 Gbps (non-blocking)
- Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables
- Dimensions (LxWxH):
280 x 120 x 25 mm (109.2 x 46.8 x 9.75 in.)
- Weight:
0.774 kg (1.71 lbs)
- Power:
12 VDC, 1 A
- Power Consumption:
2.66 W / 9.32 W
- Power Saving:
Cable connected detection, sleep mode
- Power Supply:
External
- Operating Temperature:
0–50°C (32–122°F)
- Storage Temperature:
-20–70°C (-4–158°F)
- Operating Humidity:
10–90% (non-condensing)
- Storage Humidity:
10–90% (non-condensing)
- Quality Of Service:
802.1p and DSCP
- Regulatory Compliance:
FCC Class A, CE
- Bảo hành chính hãng: 12 tháng.
