GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference.
PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion.
AUTO-SENSING PORTS
Automatically optimize speed for each connected device.
POWER-SAVING FEATURES
The auto power-down feature disables unused ports, smart power is ideal for short cable runs, and the port status switch controls LED lights.
Technical specifications
-      Network Standards:
o   IEEE 802.3
o   IEEE 802.3u
o   IEEE 802.3x
o   IEEE 802.3ab
o   IEEE 802.3az
-      Ports:
16 Gigabit Ethernet (10/100/1000) Ports
-      LEDs:
Link, speed, and activity indicators
-      Performance:
o   Full line rate and forwarding rate of 64B frame at:
o   1.488Mpps for 1000M port
o   0.1488Mpps for 100M port
o   0.01488Mpps for 10M port
-      MAC Address Table Size:
8K
-      Bandwidth:
32 Gbps (non-blocking)
-      Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables
-      Dimensions (LxWxH):
280 x 120 x 25 mm (109.2 x 46.8 x 9.75 in.)
-      Weight:
0.774 kg (1.71 lbs)
-      Power:
12 VDC, 1 A
-      Power Consumption:
2.66 W / 9.32 W
-      Power Saving:
Cable connected detection, sleep mode
-      Power Supply:
External
-      Operating Temperature:
0–50°C (32–122°F)
-      Storage Temperature:
-20–70°C (-4–158°F)
-      Operating Humidity:
10–90% (non-condensing)
-      Storage Humidity:
10–90% (non-condensing)
-      Quality Of Service:
802.1p and DSCP
-      Regulatory Compliance:
FCC Class A, CE
-      Bảo hành chính hãng: 12 tháng.
