Ratings
380…480V:
600V:
690V: |
0.75…1400 kW / 1.0…2000 Hp / 2.1…2330 A
1.0…1500 Hp / 1.7…1530 A
7.5…1500 kW / 12…1485 A |
|
Motor Control |
-
V/Hz Control
-
Sensorless Vector Control
-
Vector Control with FORCE Technology (with and without encoder)
-
Surface Mount Permanent Magnet:
-
Frames 2…7 (with and without encoder)
Frames 8…10 (with encoder)
-
Interior Permanent Magnet with and without encoder
|
|
Communications |
Embedded EtherNet/IP port standard (see Communication Option Kits). |
|
User Interface |
HIM (see Human Interface Modules for options) |
|
Enclosures |
-
IP00/IP20, NEMA/UL Type Open
-
Flange Mount
-
IP54/NEMA/UL Type 12
-
IP20, NEMA/UL Type 1 (MCC Style Cabinet)
-
IP54, NEMA Type 12 (MCC Style Cabinet)
|
|
Safety |
-
Safe Torque-Off PLe/SIL3 Cat. 3
-
Safe Speed Monitor PLe/SIL3 Cat. 4
|
|
Additional Features |
-
Automatic Device Configuration
-
Configure and control with embedded instruction sets in Studio 5000 Logix Designer
-
Predictive Diagnostics
-
Embedded EtherNet/IP port
-
Five option slots for I/O, feedback, safety, auxiliary control power, communications
-
Accurate positioning with PCAM, Indexer, Electronic Gearing, and speed/position profiling
-
Incremental and Absolute feedback supported
-
TorqProve for lifting applications
-
Pump Jack and Pump Off for oil well applications
-
Pjump and Traverse for Fibers application
-
Conformal Coating
-
DC Link Choke
-
AC line fuses included with Frame 8…10 drives
-
Roll-out design for Frame 8…10 drives
|
|
Certifications |
-
ABS (Frames 2…8, 400/480V AC)
-
C-Tick
-
c-UL-us
-
CE
-
EPRI/SEMI F47
-
GOST-R (Frames 2…8, 400/480V AC)
-
Lloyd's Register (Frames 2…8, 400/480V AC)
-
RINA (Frames 2…8, 400/480V AC)
-
RoHS compliant materials
-
TÜV FS ISO/EN13849-1 (EN954-1) with Safe Torque-Off option
|
