Features
- The HBC-100 is a smart home control gateway. It can connect both wired and wireless
peripheral devices for controlling light, window curtain, air-conditioner, audio/video,
sensor, scenario, etc.
- Multiple ways like portable remote, iPhone/iPad/Android App, or HomeScenario touch panel can be deployed to control your house.
- The HBC-100 is designed to work with HomeScenario IP Intercom system for condominium projects with central management server, so as to provide integrated security and smart home service.
- Also via HomeScenario AioT Cloud Platform, the HBC-100 can update its status on
real-time base and user can control from anywhere.
- Can expand RS-485 for wired smart home control.
- Also supports Z-Wave 2-way mesh networking, RF range up to 30m indoors.
- Provides digital input/output connections.
- Controls various home systems, e.g. light switch, thermostat, door access, window shades, security monitoring, A/V equipment, as well as scenarios.
- Controls via iPhone/iPad/Android/intercom touch panel.
- Always updates system status and allows controlling from anywhere via HomeScenario AIoT Cloud Platform.
- Works with central management server for large scale deployment with HomeScenario Smart Building System.
Đặc tính kỹ thuật
|
Interfaces |
|
LAN |
10/100Mbps |
|
Digital Input |
4 x digital inputs, terminal blocks |
|
Digital Output |
1 x digital output, terminal block, for wired alarm |
|
Serial |
RS-485, 1-way |
|
Serial |
USB |
|
Program Button |
For device program/association and factory reset |
|
Antenna |
Z-Wave |
|
Power |
9-24VDC |
|
RF Communication |
|
Protocol |
Z-Wave 2-way RF mesh network |
|
Frequency |
865-930MHz |
|
Range |
30m indoor line of sight, no obstructive |
|
LED Display |
|
Power |
Device on/off (power on: solid, power off: off) |
|
Service |
Portal connection (registered: on, not registered: off) |
|
Mode |
Security mode (Arm/Home: on, Disarm: off) |
|
Alarm |
Alarm trigger (alarm trigger: on, solved by disarm: off) |
|
Wifi |
Wifi connection (link: on, send: blink) |
|
Link |
Network connection |
|
Environmental Conditions |
|
Operational |
0°C to 45°C |
|
Storage |
-20°C to 60°C |
|
Humidity |
10% to 85% Non-condensing |
|
Protection |
Indoor |
|
Dimension |
137 x 91 x 25mm |
|
Weight |
200g |
- Bảo hành: 12 tháng.
